Cable size: 22AWG,24AWG,26AWG,28AWG,30AWG,32AWG,34AWG

Support 1080P

Support 4096*2160 resolution ratio，meet EMI requirement

Connector：24K gold plated/nickel , material with ABS plastic、tin plate, copper foil for option.

Length:1M-30M

Technical Performance

• Temperature:  80°C    Voltage: 30V

• Conductor resistance : at  20°C  MAX    30AWG : 381W/km

•  Impedance: 100±10W  at TDR   (2C+1C+AL)*4

Mechanical Performance

• Tensile Strength: before aged:1500PSI ,after aged : MIN70%

• Elongation :  before aged: 100%MIN   after aged: 65%MIN

• Thermo-shock test : no crack

• cold bending test:no crack

• Deformation Test :Max 50%

• Flame test : pass UL VW-1
