| Part Number | UTP CAT5E PVC | UTP CAT5E PVC+PE | UTP-M CAT5E-4P | FTP CAT5E-4P | |||||
| Conductor | Diameter(mm) | 0.50±0.01 | 0.50±0.01 | 0.50±0.01 | 0.51±0.01 | ||||
| Material | Cu | Cu | Cu | Cu | |||||
| Insulation | Diameter(mm) | 0.88±0.03 | 0.88±0.03 | 0.88±0.03 | 1.0±0.03 | ||||
| Material | HDPE | HDPE | HDPE | HDPE | |||||
| Shield | 1st Shield(Tape) | N/A | N/A | N/A | AL Foil | ||||
| 2nd Shield(Braid) | N/A | N/A | N/A | N/A | |||||
| Rip | Yes | Yes | Yes | Yes | |||||
| Drain wire | N/A | N/A | N/A | 0.4mm TC | |||||
| Jacket | Thickness (mm) | 0.55±0.05 | Inner Jacket | Grey PVC | 0.80±0.05 | 0.55±0.05 | |||
| Material | PVC/LSZH | Outer Jacket | LDPE | LDPE/PVC | LDPE/PVC/LSZH | ||||
| Diameter (mm) | 5.0±0.3 | 6.3±0.5 | 5.5±0.3 | 6.1±0.3 | |||||
| Color | According to the requires | Black | According to the requires | According to the requires | |||||
| Messenger | Messenger diameter (mm) | N/A | N/A | 1.30±0.03 | N/A | ||||
| Jacket diameter(mm) | N/A | N/A | 2.40±0.15 | N/A | |||||
| Thickness (mm) | N/A | N/A | 0.50±0.05 | N/A | |||||
